Description
Size: from 2″ to 48″
Pressure: 150 – 1500LB
Material: we can offer valves carried out in Duplex S31803、Super Duplex S32750、Super Duplex S32760
1A、、2A、3A、4A、5A、6A、1B、1C
CD4MCu、CD4MCuN、CD3MCuN、CE8MN、CD6MN、CD3MN、CE3MN、CD3MWCuN
F51、F53、F55、F60
Design and production standard: API 594 or DIN
Distance between flanges: ASME B16.10, EN558, DIN3202
Connected in accordance with standard: ANSI, API, DIN
Test standard: API598, API 600, ISO5208
Medium: The valve is suitable for several media including water, steam, oil, gas, petrol products, nitric acid, acetic acid, etc.
Working temperature: from -46ºC or -50ºC (stainless steel constructions) and -29ºC or -46ºC (carbon steel constructions) up to 600℃
