Screwed Stainless Steel Globe Valve

Screwed Stainless Steel Globe Valve
Our Stainless Steel Globe Valve Screwed is suitable for industrial applications including chemical plants, hospitals, paint manufacture and installations using aggressive liquids; ideally suited for isolation duty and media including air, gas, oil and water. A hand wheel operated, screwed globe valve with rising stem, Stainless Steel body, bonnet and disc.

Provides a leak tight shut off with the capability of being used partially open to regulate flow.

Key features:
Available in sizes: 1/4″ to 4″.
Temperature range: -20°C to 180°C.
Pressure rating: 200 PSI.
A maintenance free valve, perfect for isolation.
Body Material:304,316.
Manufacture:STV Valve

STV Valve Technology Group Co., Ltd is a professional leader China 200 PSI Globe Valve, Globe Valve,Screwed Globe Valve,Stainless Steel Globe Valve,Female NPT Globe Valve,I Inch Globe Valve,2 Inch Globe Valve,316 NPT Globe Valve Manufacturer with high quality and competitive price.

Please contact our sales@stvvalve.com for other materials and details.

Date Sheet:
Screwed Stainless Steel Globe Valve

Description

End Threaded: ANSI B2.1,BS 21:1973,
DIN 259/2999, ISO 228
Structure: globe valve
Pressure: 200PSI
Port size: standard
Material: WCB,304,316
Size: 1/2″-4″
Handle wheel

Product Name	Stainless Steel Globe Valve,CF8,3 Inch,200 WOG,NPT End
1. Material	CF8M
2. Size	11/2”
4. Port	Full Port
5. Working Pressure	200WOG
6. Connection Ends	NPT
7. Working Temp.	-29~120ºC,
8. Suitable Medium	Water, Natural Gas, Oil and some corrosive liquid
9. Operated	Handwheel
10. Inspection & Testing	According to API598
Shipment
Delivery Time	30 Days
Package	Standard Exporting Plywood Case
Shipping Port	Ningbo/Shanghai, China
Shipping Terms	Exw, FOB, CFR, CIF, etc.
Payment Terms	T/T, Western Union, PayPal, etc.
	30% prepayment, 70% balance paid before shipping
Country of Origin	Wenzhou city, China
Production Capacity	6000 ton/year
MOQ	1 PCS/size
